PLAN 14-239
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 38'
Width : 30'
Area
First Floor: 856 sq/ft height 8'
Porch: 165 sq/ft
Ceiling
Main Ceiling : 8'
Roof
Primary Pitch : 7:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2"x4"
Bedroom Features
Main Floor Bedrooms
Kitchen Features
Breakfast Nook
Additional Room Features
Storage Area
Lot Characteristics
Suited For Corner Lot
Suited For Narrow Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Empty Nester
Rooms
Bathroom 1:
51 sq/ft width 9' x depth 5' 9"
Bedroom 1:
144 sq/ft width 12' x depth 12'
Bedroom 1 Closet:
17 sq/ft width 5' 8" x depth 3'
Bedroom 2:
132 sq/ft width 12' x depth 11'
Bedroom 2 Closet:
21 sq/ft width 7' 2" x depth 3'
Coat Closet:
11 sq/ft width 3' 10" x depth 3'
Kitchen:
180 sq/ft width 15' x depth 12'
Laundry Room:
18 sq/ft width 6' 4" x depth 3'
Linen Closet:
13 sq/ft width 5' 4" x depth 2' 7"
Living Room:
195 sq/ft width 15' x depth 13'
Porch - Front:
75 sq/ft width 15' x depth 5'
Porch - Rear:
91 sq/ft width 15' 2" x depth 6'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$488.75
$573.75
$573.75
$573.75
$399.50
Foundation
$0.00
$0.00
Additional Options
$42.50
$85.00
$33.15
$85.00
$85.00
$0.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
