PLAN 542-1

Home > Style > Modern

Key Specs

5164
sq ft

4
Beds

6
Baths

2
Floors

1
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.

Modify This Plan

Plan Description

With large walls of glass luxury interiors and extensive outdoor spaces, this plan is a striking Contemporary that would be perfect on a view lot. The main level is an open with the kitchen, the dining, and living area with fireplace and bar. Move on to the primary with en-suite bath, Jacuzzi and dressing-room. The upper floor bedrooms are accessed through a gallery that overlooks the living area below. All rooms have private bathroom and walk-in closets. There is also a small gym with adjacent sauna-room. Another focus during the design of the house was to fill the plan with energy-saving features. The large windows allow for good solar heat control and thermo-acousutic insulation, while all other materials selected are natural and eco-friendly.

Floor Plans

Floor Plan - Upper Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Main Floor

Reverse

Full Specs & Features

Dimension

Depth : 56'

Height : 22'

Width : 92'

Area

Garage : 625 sq/ft

Main Floor : 2884 sq/ft

Upper Floor : 2415 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Garage Ceiling : 9' 10"

Main Ceiling : 20'

Upper Ceiling Ft : 10' 5"

Exterior Wall Framing

Exterior Wall Finish : Stone/plaster/wood

Insulation : Eco-friendly mineral wool/wood fibre panel

Bedroom Features

Upstairs Bedrooms

Upstairs Master Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Great Room Living Room

Main Floor Laundry

Wet Bar

Garage Features

Carport Porte Cochere

Side Entry Garage

Entryway

Friend S Entry

Lot Characteristics

Suited For Corner Lot

Suited For Sloping Lot

Suited For View Lot

Outdoor Spaces

Courtyard

Energy Efficient Features

Energy Efficient Design

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

Questions? Call 1-877-803-2251

Plan Set

PDF Set:
$1040.00

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

5 Copy Set:
$1120.00

5 printed plan sets mailed to you.

8 Copy Set:
$1200.00

8 printed plan sets mailed to you.

Reproducible Set:
$1200.00

For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

CAD Set:
$2080.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Single Set:
$984.00

One printed set for bidding purposes only. Not a legal building set for construction.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Right-Reading Reverse:
$480.00

Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets:
$480.00

Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design:
$132.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$31.20

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design:
$132.00

Receive an overlay sheet with suggested placement of lighting fixtures.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
