PLAN 17-3271
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 73' 8"
Height : 35' 2"
Width : 60'
Area
First Floor: 2391 sq/ft height 10'
Garage: 703 sq/ft
Porch: 263 sq/ft
Second Floor: 1187 sq/ft height 9'
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Stone
Framing : Wood - 2x4
Bedroom Features
Guest Suite
Kitchen Features
Breakfast Nook
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Great Room Living Room
Outdoor Spaces
Courtyard
Rooms
Bedroom 3:
215 sq/ft width 17' x depth 12' 8"
Bedroom 4:
190 sq/ft width 15' 8" x depth 12' 2"
Bedroom 5:
242 sq/ft width 22' x depth 11'
Computer Room:
231 sq/ft width 15' 8" x depth 14' 9"
Covered Porch:
223 sq/ft width 22' 4" x depth 10'
Dining Room:
158 sq/ft width 12' 8" x depth 12' 6"
Foyer:
103 sq/ft width 9' x depth 11' 6"
Garage:
675 sq/ft width 21' 4" x depth 31' 8"
Great Room:
401 sq/ft width 22' 4" x depth 18'
Guest Bathroom:
147 sq/ft width 12' x depth 12' 4"
Guest Bedroom:
147 sq/ft width 12' x depth 12' 4"
Hearth Room:
235 sq/ft width 15' 4" x depth 15' 4"
Kitchen:
217 sq/ft width 15' 4" x depth 14' 2"
Laundry Room:
107 sq/ft width 9' 8" x depth 11' 2"
Master Bathroom:
270 sq/ft width 15' x depth 18'
Master Bedroom:
240 sq/ft width 15' x depth 16'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (Walk out is not shown on elevations unless finished walk out.)
- CAD Unlimited Build comes with a free PDF.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
Plan Set
$1350.00
$1450.00
$1700.00
$2050.00
$2700.00
$2700.00
Foundation
$0.00
$0.00
$299.00
$299.00
Framing
$0.00
$299.00
Additional Options
$299.00
$80.00
$100.00
$395.00
$39.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
