PLAN 1015-18
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 65' 8"
Height : 22' 4"
Width : 60'
Area
First Floor: 2789 sq/ft
Garage: 418 sq/ft
Storage: 33 sq/ft
Roof
Primary Pitch : 6:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Block
Bedroom Features
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bedroom 2:
128 sq/ft width 11' 8" x depth 11'
Bedroom 3:
128 sq/ft width 11' 8" x depth 11'
Bedroom 4:
128 sq/ft width 11' 8" x depth 11'
Bedroom 5:
176 sq/ft width 12' x depth 14' 8"
Bedroom/Bonus Room:
266 sq/ft width 14' x depth 19'
Breakfast Room:
60 sq/ft width 9' 6" x depth 6' 4"
Dining Room:
147 sq/ft width 11' 8" x depth 12' 8"
Family Room:
323 sq/ft width 18' 4" x depth 17' 8"
Garage:
383 sq/ft width 20' x depth 19' 2"
Kitchen:
200 sq/ft width 14' 8" x depth 13' 8"
Laundry Room:
41 sq/ft width 7' 2" x depth 5' 10"
Living Room:
134 sq/ft width 12' x depth 11' 2"
Master Bathroom:
122 sq/ft width 16' 8" x depth 7' 4"
Master Bedroom:
293 sq/ft width 13' 4" x depth 22'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$977.50
$1147.50
$1275.00
$1955.00
$595.00
Foundation
$0.00
Framing
$0.00
Additional Options
$42.50
$85.00
$33.15
$85.00
$25.50
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
