PLAN 489-14
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 67'
Height : 13' 6"
Width : 61'
Area
Bonus : 229 sq/ft
Garage : 510 sq/ft
Main Floor : 1790 sq/ft
Patios : 320 sq/ft
Porch : 205 sq/ft
Ceiling
Ceiling Details : Sloped ceiling interiors up to 11 feet 6 inches.
Garage Ceiling : 8'
Main Ceiling : 11' 6"
Roof
Primary Pitch : 1:12
Roof Framing : Truss Joist
Exterior Wall Framing
Exterior Wall Finish : Stucco & Masonry Veneer
Framing : 2x4
Bedroom Features
Guest Suite
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Eating Bar
Kitchen Island
Additional Room Features
Den Office Study Computer
Exercise Room
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Media Room
Play Flex Room
Garage Features
Detached Garage
Front Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For Narrow Lot
Suited For View Lot
Outdoor Spaces
Breezeway
Covered Front Porch
Covered Rear Porch
More
Empty Nester
Suited For Vacation Home
Unusual Shape
Wheelchair Adaptable
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1785.00
$1895.00
$1985.00
$1998.00
$2098.00
$2198.00
$2685.00
$2685.00
Foundation
$0.00
Framing
$0.00
$195.00
$275.00
Additional Options
$275.00
$175.00
$275.00
$375.00
$395.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
