PLAN 58-233
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 50'
Height : 19'
Width : 54'
Area
Basement Unfinished: 1412 sq/ft
First Floor: 1542 sq/ft height 8'
Garage: 640 sq/ft height 8'
Roof
Primary Pitch : 6:12
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x4
Bedroom Features
Formal Living Room / Parlor
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Vaulted / Cathedral Ceilings
Outdoor Spaces
Covered Front Porch
Deck
Rooms
Bedroom 2:
121 sq/ft width 11' x depth 11'
Bedroom 3:
121 sq/ft width 11' x depth 11'
Dining Room:
144 sq/ft width 12' x depth 12'
Garage:
660 sq/ft width 30' x depth 22'
Living Room:
280 sq/ft width 20' x depth 14'
Master Suite:
195 sq/ft width 13' x depth 15'
What's Included In This Plan Set
- 1/4" scale fully dimensioned Foundation/Basement Plan - Also includes "future finish" Recreation Room, 1 or 2 Bedrooms, Bathroom and Storage area's. Extra Items like fireplaces and wet bars are indicated as "optional".
- 1/4" scale fully dimensioned Floor Plan - In order to simplify construction, We use the most comprehensive dimensioning method in the industry.
- 1/4" scale Front, Side and Rear Elevations - 1/4 inch scale elevations all the way around clarifies construction and helps with estimating materials and costs.
- Roof plan - An eighth-inch scale "Birds-eye" view of the roof helps to simplify construction by showing all the valleys, hips, ridges etc.
- Electrical - Shown right on the floor plan, switches and outlets are located using standards of the National Electrical Code.
- Kitchen Cabinet Details, Wall section, Stair and Fireplace Details - All drawn 1/2" scale provide easy viewing of the specific area's.
- Building Cross Section - Complete front to back cross section with basic framing details.
Plan Set
$782.00
$994.50
Foundation
$0.00
$255.00
$255.00
Framing
$0.00
$85.00
Additional Options
$127.50
$63.75
$140.25
$250.75
$33.15
$140.25
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
