PLAN 47-657

Home > Style > Victorian House Plans

Key Specs

1073
sq ft

3
Beds

1.5
Baths

2
Floors

0
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-803-2251 for assistance.

Modify This Plan

Plan Description

Perfect in a wooded or mountainous setting, this home is a relaxing and versatile vacation hideaway. A deep deck sweeps up to the entry, while a balcony offers a great view from the upper-floor master bedroom. Inside, the living room enjoys a cozy fireplace and an open layout. The kitchen boasts a window over the sink that overlooks the side yard. The adjoining dining room revels in a view of the deck, which would make the perfect spot for a meal when the weather is nice. A secondary bedroom on the main floor is located just across the hall from a full bath. Upstairs, the master bedroom hosts a good-sized closet, a French door that leads out to a private balcony, and a large storage space. Another bedroom features three big windows and accesses two more storage areas.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Full Specs & Features

Dimension

Depth : 36'

Height : 24'

Width : 24'

Area

First Floor: 672 sq/ft height 8'

Second Floor: 401 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 14:12

Roof Framing : Conventional

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : Wood - 2x6 Wood - 2x4

Bedroom Features

Fireplace

Formal Dining Room

Formal Living Room / Parlor

Kitchen Features

Breakfast Nook

Additional Room Features

Loft

Outdoor Spaces

Balcony

Covered Front Porch

Deck

Rooms

3rd BR Closet:

11 sq/ft width 5' 9" x depth 2'

Basement Foundation:

672 sq/ft width 28' x depth 24'

Bathroom 2:

30 sq/ft width 5' 11" x depth 5' 2"

Bedroom 2:

124 sq/ft width 9' 1" x depth 13' 8"

Bedroom 2 Closet:

10 sq/ft width 2' x depth 5' 2"

Bedroom 3:

97 sq/ft width 9' 1" x depth 10' 9"

Bedroom 3 Closet:

10 sq/ft width 2' x depth 5' 2"

Crawlspace Foundation:

672 sq/ft width 28' x depth 24'

Dining Room:

68 sq/ft width 8' 1" x depth 8' 5"

Hall Bathroom:

48 sq/ft width 7' 4" x depth 6' 7"

Kitchen:

65 sq/ft width 7' 10" x depth 8' 5"

Living Room:

172 sq/ft width 14' 6" x depth 11' 11"

Porch - Front:

192 sq/ft width 8' x depth 24'

Walk-In Closet:

19 sq/ft width 4' 1" x depth 4' 8"

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
